LiHCH – Halogen-Free Screened Electronic Cable
LiHCH Cable is a halogen-free screened electronic cable for low-level mA signal transmission between electronic devices, computer systems, process control units and office equipment.
Key Features
Class 5Fine-Stranded Copper
70%Approx. Copper Braid Coverage
225 VPeak Operating Voltage
FRNCHalogen-Free Insulation & Sheath
Product Overview
The LiHCH electronic cable uses bare, fine-stranded Class 5 copper conductors, FRNC HI1 insulation, an overall copper braid screen and an FRNC HM1 outer sheath. Its design is intended for signal transmission in the milliampere range. The manufacturer specifies 120 nF/km maximum operating capacitance and 225 V maximum peak operating voltage.
Construction & Technical Properties
Cable Construction
ConductorBare copper, Class 5 fine stranded
Core InsulationFRNC compound HI1
ScreenCopper braid, approx. 70% coverage
Outer SheathFRNC compound HM1
Core IdentificationDIN 47100 colour coding
Technical Properties
Peak Operating Voltage225 V
Maximum Operating Capacitance120 nF/km
Fixed Installation Temperature-30°C to +70°C
Fixed Bending Radius7.5 × outer diameter
Moving Bending Radius15 × outer diameter
Flame RetardanceIEC 60332-1-2
Halogen-FreeIEC 60754
Typical Applications
Standards & Performance
Technical notice: This manufacturer datasheet describes standard LiHCH screened FRNC electronic cable. FE180/E30 fire resistance and circuit integrity are not specified. CPR class and availability must be verified for the exact product variant. All diameters are approximate.
Technical Data & Cable Dimensions
LiHCH | Screened FRNC Electronic Cable | Klaus Faber AG
100Configurations
Class 5Copper Conductors
225 VPeak Voltage
70%Approx. Braid Coverage
| Configuration | Resistance (Ω/km) |
Outer Ø (mm) |
Copper Weight (kg/km) |
Cable Weight (kg/km) |
|---|
| Source: Klaus Faber AG, LiHCH datasheet
Values are manufacturer reference data;
outer diameters are approximate.
A dash indicates a resistance value not supplied
for that specific configuration.
FE180/E30 is not specified for this cable.
